Product Description:
A new product has been available for research purposes, mostly used for slitting of narrow roll material for the higher end of the market. The product comes with a full servo driven system, typer tension system, top brand web guiding and turret rewind, allowing it to meter and number count, eliminate static and prevent the machine from working if there is no material.
Performance and characteristics
- Web guide control by EPC SYSTEM
- Rewind is turret type, auto rotate
- Full servo motor(4 servo motor)
- Sensors are of a German Sick brand, allowing it to meter, count and quantity counters
- Plc and touch screen are used to control the system
- Magnetic VS Servo tension control
- Ability to add Static removing device
- No material no working function
Applications:
Slitting narrow roll material Slitting refers to the process of cutting a wide sheet, roll, or web into narrower sections for industrial purposes. It is mainly used for cutting narrow roll material, such as adhesive labels, sticker paper or thermal transfer ribbon. Narrow roll slitting is a major part of many industrial processes. It allows for high-speed, accurate slitting of small or hard-to-handle materials. This type of slitting is commonly used for separations and trimming in the printing or adhesive industries. Slitting narrow roll material is typically done by a narrow web slitting machine. The machine utilizes multiple knives to cut the roll material into strips at varying widths.
Customization:
Supreme FQ-350FG ADHESIVE LABEL PAPER PROCESS MACHINERY WITH MINI SLIT WIDTH 16MM VOLTAGE 380V/220V HIGH SPEED SLITTING MACHINERY REWIND
- Brand Name: Supreme
- Model Number: FQ-350FG
- Place of Origin: China
- Certification: CE
- Minimum Order Quantity: 1
- Price: Negotiation
- Packaging Details: Fumigation Wooden Box
- Delivery Time: 20-30 Working Days
- Payment Terms: TT; LC
- Supply Ability: 40sets/Month
- Unwinding Max Diameter: 700mm
- Max Material Feeding Width: 350mm
- Mini Slit Width: 16mm
- Air Supply: 0.8mpa
- Warranty: 1 Year
- Highlights: Supreme FQ-350FG ADHESIVE LABEL PAPER PROCESS MACHINERY WITH MINI SLIT WIDTH 16MM VOLTAGE 380V/220V HIGH SPEED SLITTING MACHINERY REWIND is a high speed label slitting and rewinding machine with narrow-range slitting of printed materials, full auto high speed label slitting machine with counting function paper auto, high speed slitting and rewinding machine printed label barcode turret-type slitters.
Support and Services:
ADHESIVE LABEL PAPER PROCESS MACHINERY WITH MINI SLIT WIDTH 16MM VOLTAGE 380V/220V HIGH SPEED SLITTING MACHINERY REWIND offers comprehensive technical support and services. Our experienced sales and service teams are available to answer your questions and provide the best solution for your needs. We provide technical assistance with installation, maintenance, and troubleshooting as well as a wide range of spare parts and accessories. Our services include preventive maintenance, product training, and remote monitoring. We also offer software updates and upgrades to ensure the highest performance of your machine. Our team works hard to ensure your satisfaction and provide the best experience for your ADHESIVE LABEL PAPER PROCESS MACHINERY WITH MINI SLIT WIDTH 16MM VOLTAGE 380V/220V HIGH SPEED SLITTING MACHINERY REWIND.
Packing and Shipping:
Packaging and Shipping for ADHESIVE LABEL PAPER PROCESS MACHINERY WITH MINI SLIT WIDTH 16MM VOLTAGE 380V/220V HIGH SPEED SLITTING MACHINERY REWIND:
- The machinery will be packaged in wooden crates or boxes with film wrap.
- The crates or boxes will be loaded on a pallet for shipping.
- The pallet will be loaded onto a truck for delivery.
- The truck will be tracked for delivery.
FAQ:
- Q: What is the Brand Name of ADHESIVE LABEL PAPER PROCESS MACHINERY WITH MINI SLIT WIDTH 16MM VOLTAGE 380V/220V HIGH SPEED SLITTING MACHINERY REWIND?
- A: The Brand Name is Supreme.
- Q: What is the Model Number of ADHESIVE LABEL PAPER PROCESS MACHINERY WITH MINI SLIT WIDTH 16MM VOLTAGE 380V/220V HIGH SPEED SLITTING MACHINERY REWIND?
- A: The Model Number is FQ-350FG.
- Q: Where is ADHESIVE LABEL PAPER PROCESS MACHINERY WITH MINI SLIT WIDTH 16MM VOLTAGE 380V/220V HIGH SPEED SLITTING MACHINERY REWIND produced?
- A: ADHESIVE LABEL PAPER PROCESS MACHINERY WITH MINI SLIT WIDTH 16MM VOLTAGE 380V/220V HIGH SPEED SLITTING MACHINERY REWIND is produced in China.
- Q: What is the Certification of ADHESIVE LABEL PAPER PROCESS MACHINERY WITH MINI SLIT WIDTH 16MM VOLTAGE 380V/220V HIGH SPEED SLITTING MACHINERY REWIND?
- A: ADHESIVE LABEL PAPER PROCESS MACHINERY WITH MINI SLIT WIDTH 16MM VOLTAGE 380V/220V HIGH SPEED SLITTING MACHINERY REWIND is CE certified.
- Q: What is the Minimum Order Quantity of ADHESIVE LABEL PAPER PROCESS MACHINERY WITH MINI SLIT WIDTH 16MM VOLTAGE 380V/220V HIGH SPEED SLITTING MACHINERY REWIND?
- A: The Minimum Order Quantity is 1.
-
-
Performance and characteristics
1. Web guide control by EPC SYSTEM.
2. Rewind is turret type, auto rotate.
3. With full servo motor(4 servo motor)
4. Sensor use germany sick brand, it can meter counter and quantity counter.
5. with PLC, touch screen control system
Technical Data
| model | FQ-350FG | FQ-450FG |
| Max. Slitting speed | 350 m/min |
| Max web width | 350mm | 450mm |
| Min. Slitting width | 16mm |
| Cutter installed | 8 sets |
| Max. Unwinding Dia | 700mm |
| Max. Rewinding Dia | 500mm |
| Air supply | 0.8mpa |
| weight | 1200kg |
| Dimension(L*W*H) | 1850*1200*1300 |
-
