THERMAL BOND CASH REGISTER FAX POS ATM PAPER AND OTHER SMALL RIBBON ROLL AUTOMATIC SEALING AND CUTTING MACHINE LOW TEMP
http://www.youtube.com/@labelturretrewindingmachinery
The automatic sealing and cutting machine can be used for automatic online shrink packaging of products. It uses photoelectric to automatically detect products. It can choose two modes of automatic feeding or manual feeding. It adopts half-folding film and can seal the other three sides. The constant temperature heating sealing and cutting system can be used for sealing and cutting PE and POF heat sealing films. The seal is firm and beautiful, especially suitable for POF sealing and cutting. When the product size is changed, it only needs to be simply adjusted by the hand wheel, without replacing any parts, reducing the product replacement time and making it easier to operate. The speed-adjustable front-end feeding system and the back-end storage working platform make the whole machine work truly high-speed, unmanned automatic operation
Technical parameters:
| Voltage | 220V;50/60HZ |
| Power | 1.55kw |
| Max height package | 150mm |
| Sealing size | 650*550mm |
| Speed | 15-30bags/min |
| Air pressure | 0.5MPA |
| Machine size | 1900*1000*1450mm |
| weight | 320kg |
2. Instructions for the main switch
(1) Itinerary setting
The longer the time is, the longer the excess part of the shrink film will be, and it will be unsightly after shrinking. (After shrinking the packaging material, it will produce slack phenomenon).
Note: When the time is too short, it is also possible that the sealing and cutting knife cuts to the package, usually within 0.1-0.5 seconds (but the time is different due to the thickness of the package).
(2) Counter
When the package passes the electric eye switch, and the sealing and cutting knife descends and then rises, the digits on the counter will be displayed. *(Return the digit on the counter to zero, just press the "RESET" button in the upper right corner)
(3) On the radio eye switch (installed on both sides of the conveyor belt)
When the package passes through the electric eye, the stroke setter takes effect, and the sealing and cutting knife descends for sealing and cutting.
(4) Selection switch
The manual position must be selected when installing the film or debugging the machine. At this time, the conveyor belt does not run and the electric eye is closed. The automatic position is selected for the formal packaging, at this time the conveyor belt is running and the electric eye is activated. When the packaging material touches the electric eye, the sealing knife will automatically drop. Be careful not to touch the electric eye with your hands.
(5) Sealing and cutting temperature
Usually the horizontal seal is set at about 180°C, and the vertical seal is set at about 300°C. (The material and thickness of the shrink film are different).
(6) Sealing time
Usually set at 0.8 seconds. (The material and thickness of the shrink film are different).
(7) The cylinder
Drain the water at least once a month (near the white button under the cylinder, and the water will come out). Check the oil at least once a month.
Support and Services:
THERMAL BOND CASH REGISTER FAX POS ATM PAPER AND OTHER SMALL RIBBON ROLL AUTOMATIC SEALING AND CUTTING MACHINE LOW TEMP Technical Support and Services
We provide technical support and services for THERMAL BOND CASH REGISTER FAX POS ATM PAPER AND OTHER SMALL RIBBON ROLL AUTOMATIC SEALING AND CUTTING MACHINE LOW TEMP. Our team of experienced technicians and engineers are available to help you with any questions or issues you may have. We offer a wide range of services such as installation, maintenance, troubleshooting, and repairs. In addition, we offer training and consulting to ensure that your machinery is running at its best.
At our facility, we provide a full range of services for THERMAL BOND CASH REGISTER FAX POS ATM PAPER AND OTHER SMALL RIBBON ROLL AUTOMATIC SEALING AND CUTTING MACHINE LOW TEMP. Our team of technicians and engineers are available to help you with any questions or issues you may have. From installation to maintenance, our team is fully equipped and ready to assist you.
Our goal is to provide the best technical support and services for THERMAL BOND CASH REGISTER FAX POS ATM PAPER AND OTHER SMALL RIBBON ROLL AUTOMATIC SEALING AND CUTTING MACHINE LOW TEMP. Our team of experts is available to answer any questions or concerns you may have. We take pride in providing quality service, and we are committed to ensuring your satisfaction.
Packing and Shipping:
Packaging and Shipping
THERMAL BOND CASH REGISTER FAX POS ATM PAPER AND OTHER SMALL RIBBON ROLL AUTOMATIC SEALING AND CUTTING MACHINE LOW TEMP is packaged carefully to ensure it arrives safely and in excellent condition. The machines are fully assembled, and then wrapped in film then packed with the fumigation wooden box.
Machines are shipped via air or sea freight, depending on the customer’s preference.
FAQ:
Q: What is the Brand Name of THERMAL BOND CASH REGISTER FAX POS ATM PAPER AND OTHER SMALL RIBBON ROLL AUTOMATIC SEALING AND CUTTING MACHINE LOW TEMP?
A: The Brand Name is Supreme.
Q: What is the Model Number of THERMAL BOND CASH REGISTER FAX POS ATM PAPER AND OTHER SMALL RIBBON ROLL AUTOMATIC SEALING AND CUTTING MACHINE LOW TEMP?
A: The Model Number is FQJ-550M.
Q: Where is the Place of Origin of THERMAL BOND CASH REGISTER FAX POS ATM PAPER AND OTHER SMALL RIBBON ROLL AUTOMATIC SEALING AND CUTTING MACHINE LOW TEMP?
A: The Place of Origin is China.
Q: What is the Certification of THERMAL BOND CASH REGISTER FAX POS ATM PAPER AND OTHER SMALL RIBBON ROLL AUTOMATIC SEALING AND CUTTING MACHINE LOW TEMP?
A: The Certification is CE.
Q: What is the Minimum Order Quantity of THERMAL BOND CASH REGISTER FAX POS ATM PAPER AND OTHER SMALL RIBBON ROLL AUTOMATIC SEALING AND CUTTING MACHINE LOW TEMP?
A: The Minimum Order Quantity is 1.
|
|
